The 712W30000-6002Clutch Pressure Plate is an essential component for the Sinotruk HOWO series, designed to withstand the immense torque required by heavy-duty freight and construction vehicles. With a 430mm diameter, this assembly ensures a large friction surface area, providing the necessary clamping force to engage and disengage the engine power smoothly.
Technical Specifications
| Specification | Details |
| Product Name | Clutch Pressure Plate |
| Part Number | 712W30000-6002 |
| Diameter | 430 mm |
| Application | Sinotruk HOWO, HOWO A7, T7H, TX |
| Compatible Transmission | HW13710, HW15710, HW19710 Series |
| Material | High-Grade Cast Iron & Diaphragm Spring Steel |
| Weight | 48.0 kg |
| Quality Grade | Genuine Sinotruk (CNHTC) / OEM Quality |
Professional Guidelines for Replacing the 430 Clutch Pressure Plate:
-
Preparation: Ensure the engine is cool and the vehicle is securely lifted. Clean the flywheel surface thoroughly to remove any old friction material or oil.
-
Alignment is Key: Use a professional clutch alignment tool to hold the clutch disc in place before mounting the pressure plate. This prevents input shaft damage during reassembly.
-
Cross-Pattern Tightening: Install the mounting bolts finger-tight. Then, use a torque wrench to tighten them in a star (criss-cross) pattern. This ensures even pressure distribution and prevents the plate from warping.
-
Check the Release Bearing: While the transmission is down, always inspect the clutch release bearing and the fork. We recommend replacing them alongside the 712W30000-6002(1) to avoid secondary labor costs.
-
Free Play Adjustment: After installation, adjust the clutch pedal free play according to Sinotruk’s technical manual to ensure the pressure plate fully engages.
